#Workout Wednesday – Fiscal Years + Running Sums

As a big advocate of #WorkoutWednesday I am excited to see that it is continuing on in 2018.  I champion the initiative because it offers people a constructive way to problem solve, learn, and grow using Tableau.

I was listening to this lecture yesterday and there was a great snippet “context is required to spark curiosity.”  We see this over and over again in our domain – everyone wants to solve problems, but unless there is a presented problem it can be hard to channel energy and constructively approach something.

Last pre-context paragraph before getting into the weeds of the build.  I enjoy the exercise of explaining how something works.  It helps cement in my mind concepts and techniques used during the build.  Being able to explain the “why” and “how” are crucial.

Let’s get started.

High level problem statement or requirement: build out a dashboard that shows the running total of sales and allows for the user to dynamically change the start of a fiscal year.  The date axis should begin at the first month of the fiscal year. Here’s the embedded tweet for the challenge:



Okay – so the challenge is set. Now on to the build. I like to tackle as many of the small problems that I know the answer to immediately. Once I get a framework of things to build from I can then work through making adjustments to get to the end goal.

  • numeric parameter 1 to 12 for the fiscal year start
  • calculation to push a date to the right fiscal year
  • dimension for the fiscal year
  • transformation of date to the correct year
  • running sum of sales

I’ll spare you the parameter build and go directly into the calculations that deal with the fiscal year components.

Logic as follows – if the month of the order date is less than the fiscal year start, then subtract one from the year, otherwise it’s the year.  I can immediately use this as a dimension on color to break apart the data.

The next step would be to use that newly defined year with other elements of the original date to complete the “fiscal year” transformation.  Based on the tooltips – the year for each order date should be the fiscal year.

Now that the foundation is in place, the harder part is building a continuous axis, and particularly a continuous axis of time.  Dates span from 2013 to 2017 (depending on how you’ve got your FY set up), so if we plotted all the native dates we’d expect it to go from 2013 to 2017.  But that’s not really want we want.  We want a timeline that spans a single year (or more appropriately 365 days).

So my first step was to build out a dummy date that had the SAME year for all the dates.  The dates are already broken out with the FY, so as long as the year isn’t shown on the continuous axis, it will display correctly.  Here’s my first pass at the date calculation:

That gets me the ability to produce this chart – which is SO CLOSE!

The part that isn’t working is my continuous axis of time is always starting at 1/1.  And that makes sense because all the dates are for the same year and there’s always 1/1 data in there.  The takeaway: ordering the dates is what I need to figure out.

The workaround?  Well the time needs to span more than one year and specifically the start of the axis should be “earlier” in time.  To achieve this – instead of hard coding a single year 2000 in my case, I changed the dummy year to be dependent on the parameter.  Here’s the result:

Basically offset everything that’s less than the chosen FY start to the next year (put it at the end).  (Remember that we’re already slicing apart the data to the correct FY using the previous calculations.)  The combination of these two calculations then changes the chart to this guy which is now mere formatting steps away from completion.

The full workbook is available to download here.

Tableau + Python + IoT

You’ve asked and it’s time to answer.  About a week ago I posted a teaser video on Twitter that showed how I integrated my home automation system with a Tableau dashboard.  The outcome of the video was dynamically changing three different lights in conjunction with KPI results.

So beyond the “hey this is really cool” factor of connecting lighting fixtures (or anything else for that matter) to a Tableau dashboard – there are some great practical reasons to do this.  A few great replies to the tweet were of the same sentiment of the thoughts coursing through my mind.  Use something like a light to easily indicate a status – it’s that step back from the KPI shape or the BAN (big ass number).  It’s something visible that you can glance at to immediately understand performance.

Next comes the technical components of how this gets put into place.  To achieve integration between my home automation system and Tableau I used Python.  It serves as a great integrator and took an idea to proof of concept quickly.  Python benefits this situation because several people have developed libraries and published them on GitHub to share.  And the other reason why Python was a great natural choice is because of TabPy.  TabPy allows you to connect to a Python server and run native Python code through calculated fields.  These calculated fields are served up on a Tableau sheet as a table calculations.  And in general when you’re using Python with Tableau it’s to get a number/string/boolean result out.

So just because you are supposed to use TabPy for something doesn’t mean you can’t extend it’s capabilities and use it in a completely different manner.  And that’s exactly what this integration project was about.

This project is also about taking a continuous project I have around home automation and folding in something new I learned (Python) with something I already love (Tableau).

My final caveat is this: if you’re looking to emulate what I did you’re going to need some hardware aka Philips Hue lights and a bridge.  In theory you can change this out with the home automation pieces of your choice.  If you’re unfamiliar with what home automation is – it basically works by having a controller (often called a bridge) and then different connected elements.  The controller is responsible for issuing commands to things like lightbulbs, locks, and your thermostat.  It is also the vehicle that takes how you interface with your home automation system (which is typically a mobile app) and translates those commands, routines, or programs to the elements in the system.

And specific to this project, I’m interfacing with my bridge (controller) using a Python library.  The library I chose to use was Phue, a Python library designed to fully interact with the Hue API.

First I downloaded and installed Phue into my Tableau-Python-Server environment (aka the one used for TabPy).  That allows me to call the library in my Python scripts that are passed through Tableau.  During the install process I also ran a simple script to connect the library to my bridge – a necessary dependency to get this all to work.  It makes sense that you’d have to be able to establish a link between the communication component and the lights you want to change.

The next parts are all reading through documentation, trial and error with Python, and fun with Tableau.  Here’s the final calculated fields that are driving results:

Profit Ratio KPI – this is something we’re all used to.  I’ve taken the basic Profit Ratio calculation and had it evaluate against a parameter.  Based on the evaluation the result will be either 0 or 25000.  The numbers 0 and 25000 correspond to the color hue input required for the lights.  0 is red, 25000 is green.

And here’s the calculated field that is pure Python.  In this scenario I’m not actually using Python to crunch anything and return a result, so you’ll notice that the return argument is a dummy number 1.

You will see it in the calculated field description in the editor within Tableau – to use SCRIPT_INT (or any of the SCRIPT functions) the format is: put your code in quotes and any inputs or arguments being used are called using _arg1, _arg2, _argN.  Those arguments follow the comma after the script.  In my example I have one argument, [Profit Ratio KPI] and that is being assigned to a in the code.

  • The basic outline of the code is as follows:
  • set [Profit Ratio KPI] to be a
  • import phue library so we can use it
  • use my bridge (that’s the bridge’s IP address on my internal network)
  • set the saturation of the lights to 254 – this is extra code, but ensures that the light has full saturation
  • set the light hue to the value of a
  • return 1 – just for fun!

If you’re extra interested, the functions from Phue require you to select which light you’re going to be controlling.  The Profit Ratio KPI light was number 25.

A trial and error moment here.  As I was testing this code I had a Jupyter notebook up and was entering the same code snippets to test it outside of Tableau.  Under normal circumstances I was able to assign a number to a without any issue, execute the code, and have the lights change colors.  Inside of the Tableau space I had to call the first index “[0]” of the argument.  I haven’t looked through the documentation for TabPy in enough detail, but it leads me to believe that arguments come in as lists instead of single variables.  So to isolate out the one result I wanted, I had to specify which element I wanted in my list of one variable.  So my KPI result is really like [25000] in Python notation and has to be called as _arg1[0] (non-Python folk: Python indexes start at 0).

Literally everything else about this was setup and build of the Tableau components.  Building out the BANs and adding parameters to dynamically input the goal variables.  Everything else was connected and working after the correct code was entered.

Here’s what one of the BAN sheets looks like:

The calculated field is present on detail, but not used anywhere else in the view.  (Which if you hovered over a default tooltip would show “1”).

Once the visualizations are set it’s just a matter of interacting with the dashboard to start seeing this integration take effect.  You’ll notice during the video that it’s not super fast – there is definitely an element of time.  And that makes sense – there is a bunch of overhead to take an argument from Tableau that has to be computed, push it through a Python server, and wait for a result to return.

This is a beautifully simple integration and demonstration of how to take the mantra of seeing and understanding data to the physical world.  With a few lines of code data-driven performance can exist in the physical world.

The Remaining 25 Weeks of #WorkoutWednesday

Back in July I wrote the first half of this blog post – it was about the first 27 weeks of #WorkoutWednesday.  The important parts to remember (if the read is too long) are that I made a commitment to follow through and complete every #MakeoverMonday and #WorkoutWednesday in 2017.  The reason was pretty straightforward – I wanted a constructive way to challenge myself and tangible, realistic goals.

Now that we’re 3 days into 2018 – it’s the perfect opportunity to go through the same process of sharing the impact each workout (the remaining 25) has had on me.

Week 28 | Insights & Annotations
The focus on this workout was adding context/insights/summarization to existing visualizations.  Something that is often asked of those creating dashboards or presenting data.  I enjoyed this workout tremendously because it was a great example of using a feature within Tableau in a way I hadn’t thought about.  The premise is pretty simple – allow users the ability to input insights/findings and customize the summary output.  Very clever use that is a great way to provide a dashboard to someone who has little time or is skeptical of self-service analytics.

Week 29 | Who sits where at the Data School?
I hated this workout – because of donut charts.  Donut charts in Tableau are the level one “look how cool I am” or “I think I’m pretty awesome with the tool” things that people make.  Yes – they are cuter than pie charts (which I don’t mind) – but I strongly hate how these are implemented in Tableau.  Pushing aside my dissatisfaction for donuts – I veered off requirements for this dashboard.  I particularly changed from the original build results because of how seat favorites were computed – more specifically I ended up with more “No Favorite” than the original.  The great points about this workout – the sophistication required to calculate several of the numbers shown.

Week 30 | Loads of LODs
As described this workout had a few LODs.  The most distinct thing I remember about this build relates to the region filter.  You need to decide early on how you’re going to implement this.  I believe Emma used a parameter where I used a filter.  The choice made here will have consequences on the visualizations and is a great way to start understanding the order of operations within Tableau.

Week 31 | The Timing of Baby Making
Ah – a favorite visualization of mine, the step chart/plot.  The two major gotcha moments here are: implementing the step chart and the dropdowns/filters to set highlighting.  This one is solvable in multiple ways and I went the Joe Mako route of unioning my data set.  During the build this seemed like the easier solution to me, but it does have implications later on.  I believe it’s worth the effort to go this route – you will learn a lot about how unioning your data on itself can be useful.

Week 32 | Continuous Dates are Tricky
This is classic Emma style – particularly down to the requirement of a dynamic title that would update based on newer data availability.  The premise itself is pretty straightforward – how can you plot a continuous month line, but have years broken out.  By definition that concept should break your brain a bit, because continuous means it’s the entire date, so how are you plotting different years on a continuous axis?  And hence the challenge of the workout!

Week 33 | How Have Home Prices Changed?
Andy mentioned that this visualization was inspired by Curtis Harris.  And as I write this – it is probably my top visualization in terms of design from the 2017 #WorkoutWednesday collection.  Something about the strategic use of capitalization in conjunction to the color choices resonated with me and has left a lasting impact on my viz style.  This is a stunningly beautiful example of making Tableau a very self-service analytics tool, having dense data, but still being deceptively simple and clean from a design perspective.  Plus you’re practicing dynamic titles again – which I find to be a requirement for most serious builds.

Week 34 | Disney’s Domination
This workout was my first waffle chart.  I’d successfully avoided the waffle (as a general rule I don’t like high carbohydrate visualizations) up to this point.  More than the waffle – was the requirement to data blend.  I’m not a big data blending fan because it is very easy for things to go sideways.  However – the icky feeling you get from data blending is exactly why this is a great exercise to work through.  And also because I believe I did this entire visualization (up to a point) using LODs and had to switch to table calculations.  I learned how to make an LOD into a table calculation (probably the reverse practice for more tenured Tableau folks).

Week 35 | Average Latitude of Solar Eclipses by Century
This is another visualization with design that I find very pleasing – particularly the use of reference lines.  I strongly remember learning so much about the Path shelf this week.  Specifically how to use path to your advantage.  You don’t often see people create something that would otherwise be a line chart, but instead has vertical bars/gantts/lines to focus the eye vertically and then across.  A great exercise and thought-starter on additional visualizations to make.

Week 36 | Which UK Airport Should You Fly From?
This workout is the perfect hands-on exercise on taking continuous sizing on bar charts offered up as a new feature in the past year.  Beyond knowing that you CAN do something, knowing HOW to build that something is the key (at least for me) to be able to iterate and ideate.  This one is more complex than it seems at first glance.

Week 37 | Killings of Blacks by Whites Are Far More Likely to Be Ruled ‘Justifiable’
A viz I don’t want to remember – this one is 100% about formatting.  It took me a considerable chunk of time to complete.  And probably more maddening – this viz needs to be built in one session, otherwise you’ll forget all the intricate details required to make it look “just so.”  I was cursing my PC the entire build – and worse than that I think I restarted it at a certain point because things weren’t lining up how I wanted.  Only complete if you enjoy being tormented.  The upside?  Going through this workout will make you intimately aware of all the gaps and limitations Tableau has as it relates designing.  Also – this was done before changing padding was a feature.  Thanks guys.

Week 38 | (It Takes) All Sorts
This is another “looks simple” but has “some tricks” workout.  I remember someone at our user group asking about this over the summer and if I knew how to build it.  I didn’t have an answer readily available within 30 seconds, so I knew there was more going on.  I highly encourage this build because it demonstrates how sorting works and how multiple sorts interact with each other.  Also – I think whatever sorting I ended up was some sort of mathematical manipulation on my part.

Week 39 | Are the contributions of top sellers increasing throughout the year?
Another trellis chart!   More than the trellis – check out what is being analyzed.  This isn’t superficial or first-pass reading of data.  This is second and third level thought on finding deeper insights and answers to questions within a data set.  So naturally it requires more layers of calculations to resolve.  And of course – the “just so” placement of the far right label.  This is a perfect example of taking a question and turning it into a visualization that shows the answer.

Week 40 | All Sorts Part 2
As advertised and named – the second half of Emma’s sorting workout.  This may actually have been the dashboard where I did some mathematical magic to require the first position to be first and retain any additional sorting.  Also – the devil is in the details.  When you change sort order, notice that the bottom visualization always changes to be the subcategory chosen.  Sounds easy, but takes some thought to implement.

Week 41 | State to City Drill Down
As I look back on my tracker – I realize that I did 38 through 41 in the same day.  And naturally I approach backlog in the fashion of oldest gets built first.  So this was the 4th on a particular day – but I championed this guy hardcore.  I will say it again – YOU NEED TO DO THIS WORKOUT.  The concepts on execution here are next level.  I know it sounds kind of trivial – but it will help unlock your mind to the possibilities of using filters and the art of the possible.  Plus this is a question that ALWAYS gets asked.  “Can I click a state and have it automatically change the view to cities.”  This does that.  Also – this build took me 30 minutes tops.

Week 42 | Market Basket Analysis
I won’t forget this workout anytime soon because it required the legacy JET connector and thinking about how data gets joined back on itself.  This type of analysis is something people often want to have done – so knowing the steps on creation using an Excel data source (or other sources for that matter) makes this guy worth the build.  Follow Emma’s advice closely.

Week 43 | The Seasonality of Superstore
A great viz once again demonstrating how powerful parameters can be – how you can use them in multiple places – and also things you can do to make visualizations more user/reader friendly.  You’re definitely using a table calculation somewhere in here – and you definitely will get angry when trying to recreate the smoothing (particularly dealing with endpoints of the chosen time range).

Week 44 | Customer Cohorts
When dealing with cohort analysis you’re very likely to encounter LODs – that’s par for the course for this workout.  But again – Emma is so clever at taking something that seems straightforward and challenging you to implement.  If you look closely you’ll have to dynamically change the bottom visualization based on where a user clicks.  I remember spending the majority of my time on the dynamic title.



Week 45 | Stock Portfolio
This is one sheet.  Just remember that – everything is on one sheet.  And more than that – think about how this is implemented from a numerical perspective – there’s some serious normalization going on to make things show up in context to one another.  If you’re not a math lover – this will be a great way to play with numbers and have them bend to your advantage.  Also – I remember being annoyed because one of the stocks had a maximum value greater than the recorded max (which is it’s own measure) – and that irritated me.

Week 46 | Top N Customers
Think of this as a different way of implementing sets.  It has a lot of similar functionality between IN/OUT and showing members of a set.  And also there are some key takeaways in terms of aggregating dimensions.  Not super flashy on design, but very useful in terms of implementation.

Week 47 | Fun with Formatting
Another visualization where you’re required to do everything in a single sheet.  This will put all that table calculation sweat to action.  I really enjoyed this one.  There is something very satisfying about ranking/indexing things multiple ways in one view.  Also it uses the Caption guys.

Week 48 | Treemap Drilldown
Same concept as week 41, but executed as a treemap.  I think I even opened up week 41 to use as influence on where to go.  Same concepts are repeated, but in a different format.  The automagic of this one doesn’t get old – also carefully look at how things are sorted.

Week 49 | Position of Letter Occurrences in Baby Names
When you say out loud what you’re trying to do – particularly “find the nth occurrence” of a specific letter (we can generalize as substring) in a specific string – it sounds really really hard.  But guess what – there’s a built in function!  The fact that it’s built in made this visualization super straightforward to complete.  You should build this to introduce yourself to a function you’ve probably never used before.

Week 50 | Rocket ship Chart
I very much enjoy this type of chart from an analytical perspective.  It’s a great way to normalize things that are bound to time.  You see immediate inferred rank and results.  Emma put in some requirements to ensure that as data changed this chart would stay accurate.

Week 51 | State by State Profit Ratio
If you want several of the lessons Andy built into multiple workouts all in one place – this workout is for you.  It’s got so many classic Kriebel “gotcha” moments in it.  As I was building this I really felt like it was a specially designed final to test what I’ve learned.  Also this is probably my first tilemap (unless we made one in another workout).  I don’t use them often – so it’s a great refresher on how to implement.  And also – you get to use a join calculation.

Week 52 | UK’s Favourite Christmas Chocolates
When I was building this one someone asked me why I was making it – specifically where was the challenge.  I explained that it was all in one sheet opposed to 4 different sheets.  A natural next question occurred which was “why would you want to do it in one sheet.”  I though that was a very interesting question and one that I explained by saying that for me personally knowing multiple ways to do things is important.  And more specifically as I know to be true of these types of builds – if you can do it in one sheet, it shows a level of mastery on making Tableau do exactly what you want (which is LOTS of things).

And that wraps up 2017 beautifully.  Comparing the retrospective of this half of the year vs. the first half – there are stark differences from my perspective.  I can honestly say that each build got easier as time went on.  Once I got to the last few challenges – I was timing completion to be about 20 minutes.  Contrast that with the first few weeks where I spent hours (over multiple sessions) making my way through each build.

Beyond building out my portfolio, having concrete examples of specific types of analysis, and fulfilling my own goals – #WorkoutWednesday has given me such depth of knowledge in Tableau that it’s ridiculous.  You know how people say things like “that’s just funny Tableau behavior” – well I can (for the most part) now verbally articulate what and why that funny behavior is.  And more than that – I know how to maximize the behavior which is really working as designed and use it to my own advantage.

The last part of this blog series is going to be a ranking of each workout – aimed to help those who are interesting in completing the challenges approach these without getting too discouraged or burnt out on some of the builds that are still (to this day) hard.  Be on the lookout.

Exploring Python + Tableau

This month I’ve been taking a night class at Galvanize aimed at being an introductory to Python and Data Science.  It’s a 4 night/week boot camp with a mix of lecture and hands-on assignments.  My primary interest with the course was the data science component, but I also felt extremely strong about the necessity to have a programming language in my toolkit.

To add context – I’ve taken formal classes in C++ and Java, know enough HTML/Javascript to be dangerous, and can leverage SQL when forced.  I’ve always had very positive retrospective moments about learning C++ and particularly think the act of writing pseudo-code has been a skill I’m lucky to have.

When learning anything new I think it’s required to put it in action.  So I have some small immediate goals related to Python that focus on integration or utility to Tableau.  In fact earlier this year I dabbled in the topic and spun up a Linux box to go through the published exercise of using Python+NLP.  Specific to that exercise I actually did the NLP processing within Python and exported the results.

This leads me to Wednesday, where I was presented with a new opportunity to combine skill sets.  The premise was pretty straightforward – take concepts of Monte Carlo scenarios/simulations/method for corporate finance and use it to develop visualizations.  The key to this is that a historic input or perhaps expected input (likely derived through some analysis) and it’s corresponding standard deviation are used along with the probability component of random numbers bounded to a normal distribution.  A fancy way of saying (at least for this example) – generate numbers based on X, it’s standard deviation, and random numbers.  Specifically of the format Result = X + (SD*RandomNumber).  And several results are computed.  It’s like rolling dice over and over again and seeing what happens.

So this initially was conceived and in working order in Excel – and the kicker of why it works in Excel is a function that does that tidbit I mentioned above “random numbers bounded to a normal distribution.”  The functions used to generate that aren’t available in Tableau.  And this is where Python came to the rescue.

Because Python has depth in mathematical libraries it seemed like a natural choice to outsource the computation of these random numbers to it.

To get started I read through this community article: Tableau Integration with Python – Step by Step.  It provides the pertinent components of how to get Tableau and Python to talk – most specifically how to use the SCRIPT_() functions in Tableau to pass through Python code to TabPy.

Once that was done I needed to develop a data set to use under the hood of the workbook (remember pretty much everything is parameterized – so there’s no data to read in).  I ended up making an Excel spreadsheet with 1,000 rows – each with a row number (1 to 1,000).

The simulation results are this calculation:

So you can see – 2 parameters (purple) and then one calculated field.  The calculated field is where Python jumps on the scene.

Breaking this down a bit further:

  • SCRIPT_REAL() – takes in blocks of code within quotation marks followed by arguments (that must be aggregated).   It outputs a real number (opposed to integer, string, or boolean)
  • Python script is pretty basic: import 2 different libraries
    • norm from scipy.stats – this gives me the function norm.ppf() that allows the conversion of a random number to be in that normal distribution format
    • random.random() – just a random number function
    • Named n as a list and set it equal to the output of my functions
    • returned the value n

I noticed when I did this I had to supply an argument (essentially a comma with SOMETHING after it to avoid errors in my calculated field).  So I added on a simple SUM(1).  This calculation is being called at a row level, so it’s just 1 and not used anywhere.  If I were going to use it, I’d need to include _arg1 (or _arg2, _argN) and follow up with those input arguments separated by commas.

SCRIPT() calculations always come on as Table Calculations – so you’ll see the icon and have all the nuance of Table Calculations.  Namely that they’re computed in the view and you can’t make something like bins with them or use them for sorting.

Here’s the final dashboard (in it’s initial state):

You’ll see the different inputs and the ability to set the number of simulations.  This is simply a parameter that limits the row number of the underlying data.

As I was playing around this – one of the keys to this analysis is to show the spread of the different results (ideally maybe a histogram).  So I stuck with confetti for now, but added on reference bands and lines.  Additionally I colored the simulation results using a custom binning technique where I find the range between Min & Max, divide that by 10 and then create bins with the Min+ multiple of range/10.  Here’s the calculated fields:

This allows the end user to click on the color legend to see the number of simulations within each “bin.”  And to see through random chance how the simulations really distributed.

I also made this sheet, which has some advantages of expressing that concept a bit more clearly.  Through 110 simulations – here’s where the results fell out.

In terms of the visual outputs – I’d still say I’m at an exploration stage of finding what works best.  However, from a Python/TabPy angle – I was pretty enthused to put it all in action.  And most specifically one thing I appreciate about this is that when the simulation number is changed, it’s the act of running a “new simulation.”  Same with all of the parameters – but something very satisfying about the act of data changing on the fly.

Next week we’re finally tackling NumPy and Pandas – so I expect some inspiration to come.



A follow up to The Women of #IronViz

It’s now 5 days removed from the Tableau Conference (#data17) and the topic of women in data visualization and the particularly pointed topic of women competing in Tableau’s #IronViz competition is still fresh on everyone’s mind.

First – I think it’s important to recognize how awesome the community reception of this topic has been.  Putting together a visualization that highlights a certain subsection of our community is not without risk.  While going through the build process, I wanted to keep the visualization in the vein of highlighting the contributions of women in the community.  It wasn’t meant to be selective or exclusive, instead, a visual display of something I was interested in understanding more about.  Despite being 5 days removed from the conference, the conversations I’ve been involved in (and observed from a distance) have all remained inclusive and positive.  I’ve seen plenty of people searching for understanding and hunting for more data points.  I’ve also seen a lot of collaboration around solutions and collecting the data we all seek.  What I’m thankful that I have not witnessed is blame or avoidance.  In my mind this speaks volumes to the brilliant and refined members of our community and their general openness and acceptance of change, feedback, and improvement.

One thing circling the rounds that I felt compelled to iterate off of, is @visualibrarian’s recent blog post that has interview style questions and answers around the topic.  I am a big believer in self reflection and exploration and was drawn to her call to action (maybe it was the punny and sarcastic nature of the ask) to answer the questions she put forth.

1. Tell me about yourself. What is your professional background? When did you participate in Iron Viz?

My professional background is that of a data analyst.  Although I have a bachelor’s degree in Mathematics, my first professional role was as a Pharmacy Technician entering prescriptions.  That quickly morphed into someone dedicated to reducing prescription entry errors and built on itself over and over to be put in roles like quality improvement and process engineering.  I’ve always been very reliant on data and data communication (in my early days as PowerPoint) to help change people and processes.  About 2 or 3 years ago I got fed up with being the business user at the mercy of traditional data management or data owners and decided to brute force my way into the “IT” side of things.  I was drawn to doing more with data and having better access to it.  Fast-forward to the role I’ve had for a little over 8 months as a Data Visualization Consultant.  Which essentially means I spend a significant amount of my time partnering with organizations to either enable them to use visual analytics, improve the platforms that they are currently using, or overcoming any developmental obstacles they may have.  It also means I spend a significant amount of time championing the power of data visualization and sharing “best practices” on the topic.  I often call myself a “data champion” because I seek simply to be the voice of the data sets I’m working with.  I’m there to help people understand what they’re seeing.

In terms of Iron Viz – I first participated in 2016’s 3rd round feeder, Mobile Iron Viz.  I’ve since participated in every feeder round since.  And that’s the general plan on my end, continue to participate until I make it on stage or they tell me to stop 🙂

2. Is Tableau a part of your job/professional identity?

Yes – see answer to question #1.  It’s pretty much my main jam right now.  But I want to be very clear on this point – I consider my trade visual analytics, data visualization, and data analytics.  Tableau is to me the BEST tool to use within my trade.  By no means the only tool I use, but the most important one for my role.

3. How did you find out about Iron Viz?

When I first started getting more deeply involved in my local User Group, I found out about the competition.  Over time I became the leader of my user group and a natural advocate for the competition.  Once I became a part of the social community (via Twitter) it was easy to keep up with the ins and outs of the competition.

4. Did you have any reservations about participating in Iron Viz?

Absolutely – I still have reservations.  The first one I participated in was sort of on the off chance because I found something that I want to re-visualize in a very pared down elegant, simplistic way.  I ended up putting together the visualization in a very short period of time and after comparing it to the other entries I felt my entry was very out of place.  I tend to shy away from putting text heavy explanations within my visualizations, so I’ve felt very self-conscience that my designs don’t score well on “story telling.”  It was also very hard in 2016 and the beginning of 2017.  Votes were based off of Twitter.  You could literally search for your hashtag and see how many people liked your viz.  It’s a very humbling and crushing experience when you don’t see any tweets in your favor.

5. Talk me through your favorite submission to Iron Viz. What did you like about it? Why?

Ah – they are all my favorite for different reasons.  For each entry I’ve always remained committed and deeply involved in what the data represents.  Independent of social response, I have always been very proud of everything I’ve developed.  For no other reason than the challenge of understanding a data set further and for bringing a new way to visually display it.  My mobile entry was devastatingly simple – I love it to death because it is so pared down (the mobile version).  For geospatial I made custom shapes for each of the different diamond grades.  It’s something I don’t think anyone in the world knows I did – and for me it really brought home the lack of interest I have in diamonds as rare coveted items.

6. What else do you remember about participating in Iron Viz?

The general anxiety around it.  For geospatial 2017 I procrastinated around the topic so much.  My parents actually came to visit me and I took time away from being with them to complete.  I remember my mom consoling me because I was so adamant that I needed to participate.

Safari and Silver Screen were different experiences for me.  I immediately locked in on data sets on subjects I loved, so there was less stress.  When I did the Star Trek entry I focused on look and feel of the design and was so stoked that the data set even existed.  Right now I am watching The Next Generation nightly and I go back to that visualization to see how it compares to my actual perception of each episode (in terms of speaking pace and flow).

7. Which Iron Viz competitions did you participate in, and why?

Everything since 2016 feeder round 3.  I felt a personal obligation and an obligation to my community to participate.  It was also a great way for me to practice a lot of what I tell others – face your fears and greet them as an awesome challenge.  Remain enthusiastic and excited about the unknown.  It’s not always easy to practice, but it makes the results so worth it.

8. What competitions did you not participate in, and why?

Anything before mobile – and only because I (most likely) didn’t know about it.  Or maybe more appropriately stated – I wasn’t connected enough to the community to know of it’s existence or how to participate.

9. Do you participate in any other (non Iron Viz) Tableau community events?

Yes – I participate in #MakeoverMonday and #WorkoutWednesday.  My goal for the end of 2017 is to have all 52 for each completed.  Admittedly I am a bit off track right now, but I plan on closing that gap soon.  I also participate in #VizForSocialGood and have participated in past User Group viz contests.  I like to collect things and am a completionist – so these are initiatives that I’ve easily gotten hooked on.  I’ve also reaped so many benefits from participation.  Not just the growth that’s occurred, but the opportunity to connect with like-minded individuals across the globe.  It’s given me the opportunity to have peers that can challenge me and to be surrounded by folks that I aspire to be more like.  It keeps me excited about getting better and knowing more about our field.  It’s a much richer and deeper environment than I have ever found working within a single organization.

10. Do you have any suggestions for improving representation in Iron Viz?

  • Make it more representative of the actual stage contest
  • Single data set
  • Everyone submits on the same day
  • People don’t tweet or reveal submissions until contest closes
  • Judges provide scoring results to individual participants
  • The opportunity to present analysis/results, the “why”
  • Blind submissions – don’t reveal participants until results are posted
  • Incentives for participation!  It would be nice to have swag or badges or a gallery of all the submissions afterward

And in case you just came here to see the visualization that’s set as the featured image, here’s the link.

#data17 Recap – A quick top 5

Now that Tableau Conference 2017 has come to a close it’s time to reflect back on my favorite and most memorable moments.  I’ll preface by saying that I had very lofty goals for this conference.  It started after #data16 – immediately after the conference I did some significant thought work on what I wanted my year to look like and HOW I wanted to shape it.  It began by deeply examining my why.  My why is a personal mission that transcends my professional career.  I firmly believe that visualizing data is the BEST way to get closer to the truth and to grow, learn, and improve.  I also strongly feel that every individual should use analytics in making decisions.

Without further ado – here’s my top 5.

#1 – Participating in #MakeoverMonday live

This is my number one because it represents the culmination of a lot of my personal growth and effort this year.  Coming out of #data16 I committed myself to doing every #MakeoverMonday and most specifically participating in this event.  I’ll admit I have a few weeks still outstanding, but I’m on track to have a full portfolio by the end of 2017.  This was also the moment I was most anxious about.  Would I be able to develop something in an hour AND feel comfortable enough to share it with a large audience?  Well at the end of the hour I accomplished everything I had been anticipating and more.  With the support of the amazing #MakeoverMonday family and those around me I got up and presented my viz.  And to boot it became a Viz of the Day (VOTD) the following day.  Talk about a crowning achievement.  Taking something that I had a bit of nerves about and turning it into a super proud moment.

#2 – Community Battle: 60 Second Viz Tips

I think the picture says it all.  A rapid fire tips battle at 9 am the day after Data Night Out?  YES please.  This session was an unbelievable joy to participate in.  Birthed out of the minds of the amazing London Tableau User Group and brought to the sessions of conference.  As if by fate the first community folks that found me when I dropped in on Vegas were none other than Paul Chapman and Lorna Eden.  I can’t be more grateful for the opportunity to contribute to the conference.  And let’s not forget the trophy guys.  This is a new tradition I’d love to see carry out into the conferences to come.

#3 – The Vizzies!

A pure demonstration of the awesome Tableau community that exists globally.  I was so honored to be recognized this year as a Community Leader.  Just take a look at the amazing folks that I am so thankful to be surrounded by.  More than being recognized, the fact that the community was so prominent is unbelievable.  I couldn’t go anywhere without being stopped and having conversations, hugs, or smiles shared between community members.

#4 – Iron Viz!

As I always say – the pinnacle when it comes to Tableau.  The chance to see what 20 minutes of extreme vizzing looks like from the front row.  This one is near and dear to my heart because I submitted for each of the feeder contests this year.  I’d love the opportunity to get up on the big stage and participate, but barring that – it’s an enthusiast’s dream to see the excitement play out on the big stage.

#5 – Fanalytics

Although it is coming in at my #5, this is probably the highest impact moment of conference.  A 3+ hour conversation started by important members of the Tableau community talking about their journey and growth.  It ended with me facilitating one of 8 conversations about important topics the community is facing.  Mine was focused on female participation in #IronViz.  What was interesting about this was the massive feeling that we needed more data to wrap our arms around the topic.  And this has become my first action item post-conference.  I wanted to extend the conversation beyond the round table of remaining conference goers and into the broader community.

I’ve been so inspired, impressed, and energized by all the community and people I encountered over the past week.  I can’t wait to see what the next 12 months look like.

And now that I’ve provided my top 5, I’m curious – what are your top #data17 moments?

Don’t be a Bridge, Instead be a Lock

Lately I’ve spent a lot of time pondering my role in the world of data.  There’s this common phrase that we as data visualization and data analytics (BI) professionals hear all the time (and that I am guilty of saying):

“I serve as the bridge between business and IT.”

Well – I’m here to say it’s time to move on.  Why?  Because the bridge analogy is incomplete.  And because it doesn’t accurately represent the way in which we function in this critical role.  At first glance the bridge analogy seams reasonable.  A connector, something that joins two disparate things.  In a very physical way it connects two things that otherwise have an impasse between them.  The business is an island.  IT is an island.  Only a bridge can connect them.  But is this really true?

Instead of considering the two as separate entities that must be connected, what if we rethought it to be bodies of water at different levels?  They touch each other, they are one.  They are the same type of thing.  The only difference is that they are at different levels, so something like a boat can’t easily go between them.  Is this not what is really happening.  “The business” and “IT” are all really one large organization – not two separate, foreign entities.

This is where the role of being the Lock comes in.  A lock is the mechanism by which watercraft are raised or lowered between waterways.  And to a large extent it is a better analogy to our roles in data.  We must adapt to the different levels of business and IT.  And more importantly it is our responsibility to form that function – and to get the boat (more specifically “the data”) through from one canal to the other.

Even exploring what Wikipedia says about a lock – it fits better.

“Locks are used to make a river more easily navigable, or to allow a canal to cross land that is not level. ”

“Larger locks allow for a more direct route to be taken” [paraphrased]

Is this not how we function in our daily roles?  How fitting is it to say this:

“My role is to make your data more easily navigable.  My goal is to allow data to flow through on your level.  I’m here to allow a more direct route between you and your data.”

It feels right.  I’m there to help you navigate your data through both IT and business waters.  And it is my privilege and honor to facilitate this.  Let’s drop the bridge analogy and move toward a new paradigm – the world where we are locks, adjusting our levels to fit the needs of both sides.

Boost Your Professional Skills via Games

Have you ever found yourself in a situation where you were looking for opportunities to get more strategic, focus on communication skills, improve your ability to collaborate, or just stretch your capacity to think critically?  Well I have the answer for you: pick up gaming.

Let’s pause for a second and provide some background: I was born the same year the NES was released in North America – so my entire childhood was littered with video games.  I speak quite often about how much video gaming has influenced my life.  I find them to be one of the best ways to unleash creativity, have a universe where failure is safe, and there is always an opportunity for growth and challenge.

With all that context you may think this post is about video games and how they can assist with growing out the aforementioned skills.  And that’s where I’ll add a little bit of intrigue: this post is actually dedicated to tabletop games.

For the past two years I’ve picked up an awesome hobby – tabletop gaming.  Not your traditional Monopoly or Game of Life – but games centered around strategy and cooperation.  I’ve taken to playing them with friends, family, and colleagues as a way to connect and learn.  And along the way I’ve come across a few of my favorites that serve as great growth tools.

Do I have you intrigued?  Hopefully!  Now on to a list of recommendations.  And the best part?  All but one of these can be played with 2 players.  I often play games with my husband as a way to switch off my brain from the hum of everyday life and into the deep and rich problems and mechanics that arise during game play.

First up – Jaipur

Jaipur is only a 2 player game that centers around trading and selling goods.  The main mechanics here are knowing when to sell, when to hold, and how to manipulate the market.  There are camel cards that get put in place that when returned cause new goods to appear.

Why you should play: It is a great way to understand value at a particular moment in time.  From being first to market, to waiting until you have several of a specific good to sell, to driving changes in the market by forcing your opponent’s hand.  It helps unlock the necessity to anticipate next steps.  It shows how you can have control over certain aspects (say all the camels to prevent variety in the market), but how that may put you at a disadvantage when trying to sell goods.

It’s a great game that is played in a max of 3 rounds and probably 30 minutes.  The variety and novelty of what happens makes this a fun to repeat game.

Hanabi

Hanabi is a collaborative game that plays anywhere from 2 to 5 people.  The basic premise is that you and your friends are absentminded fireworks makers and have mixed up all the fireworks (numeric sets 1 to 5 of 5 different colors).  Similar to Indian Poker you have a number of cards (3 or 4) facing away from you.  That is to say – you don’t know your hand, but your friends do.  Through a series of sharing information and discarding/drawing cards everyone is trying to put down cards in order from 1 to 5 for particular colors.  If you play a card too soon then the fireworks could go off early and there’s only so much information to share before the start of the fireworks show.

This is a great game to learn about collaboration and communication.  When you’re sharing information you give either color or numeric information to someone about their hand.  This can be interpreted several different ways and it’s up to the entire team to communicate effectively and adjust to interpretation style.  It also forces you to make choices.  My husband and I recently played and got dealt a bunch of single-high value cards that couldn’t be played until the end.  We had to concede as a team that those targets weren’t realistic to go after and were the only way we could end up having a decent fireworks display.

Lost Cities

This is another exclusively two player game.  This is also a set building game where you’re going on exploration missions to different natural wonders.  Your goal is to fill out sets in numeric order (1 to 10) by color.  There’s a baseline cost to going on a mission, so you’ll have to be wise about going off on a mission.  There are also cards you can play (before the numbers) that let you double, triple, or quadruple your wager on successfully going on the exploration.  You and your opponent take turns drawing from a pool of known cards or from a deck.  Several tactics can unfold here.  You can build into a color early, or completely change paths once you see what the other person is discarding.  It’s also a juggling act to decide how much to wager to end up making money.

Bohnanza

This one plays well with a widespread number of players.  The key mechanic here is that you’re a bean farmer with 2 fields to plant beans.  The order in which you receive cards is crucial and can’t be changed.  It’s up to you to work together with your fellow farmers at the bean market to not uproot your fields too early and ruin a good harvest.  This is a rapid fire trading game where getting on someone’s good side is critical and you’ll immediately see the downfall of holding on to cards for the “perfect deal.”  But of course you have to balance out your friendliness with the knowledge that if you share too many high value beans the other farmers may win.  There’s always action on the table and you have to voice your offer quickly to remain part of the conversation.

The Grizzled

The Grizzled is a somewhat melancholy game centered around World War I.  You’re on a squad and trying to successfully fulfill missions before all morale is lost.  You’ll do this by dodging too many threats and offering support to your team.  You’ll even make speeches to encourage your comrades.  This game offers lots of opportunities to understand when and how to be a team player to keep morale high and everyone successful.  The theme is a bit morose, but adds context to the intention behind each player’s actions.

The Resistance

Sadly this requires a minimum of 5 people to play, but is totally worth it.  As the box mentions it is a game of deduction and deception.  You’ll be dealt a secret role and are either fighting for victory or sabotage.  I played this one with 8 other colleagues recently and pure awesomeness was the result.  You’ll get the chance to pick teams for missions, vote on how much you trust each other, and ultimately fight for success or defeat.  You will get insight into crowd politics and how individuals handle situations of mistrust and lack of information.  My recent 9 player game divulged into using a white board to help with deductions!

Next time you’re in need of beefing up your soft skills or detaching from work and want to do it in a productive and fun manner – consider tabletop gaming.  Whether you’re looking for team building exercises or safe environments to test how people work together – tabletop games offer it all.  And in particular – collaborative tabletop games.  With most games there’s always an element of putting yourself first, but you will really start to understand how individuals like to contribute to team mechanics.

The Importance of Certification

I’ve long been a huge advocate of certification in technical fields.  I think it is a great way to actively communicate and demonstrate the skill level you have in a particular area.  Even further in my mind it represents the ability to set a foundation to build off of with others.

I personally started my Tableau certification journey last year (more like 18 to 20 months ago).  I was becoming much more heavily involved in my local Tableau user group and felt that I needed a way to benchmark or assess my skills.  I knew I had much more to contribute to my local community and I thought that going through the certification journey and sharing that with the TUG would be beneficial.

So I started by getting ready for the Desktop Qualified Exam.  Independently I went through all the existing documentation and searched for knowledge nuggets that would set me on the right path.  I took the stance of developing out all of my own knowledge gaining to a format that could be digested by a larger audience.  I walked through all of the practice exam questions and did an analysis of the different certification levels to the user group at least 3 times.

I passed the Desktop Qualified Associate around April or May of 2016.  It was a great achievement – and I was able to add definition to what that exam means.  Having the Desktop Qualified Associate certification means that you are technically proficient in the features and functions of Tableau Desktop.  It means that you can answer thoughtful questions using built in features and that you have depth of understanding best practices or efficient ways to get to the results.  If I were to equate it to a different skill – I would say that it means you know how and when to use different tools in a toolbox.  What it doesn’t mean: that you are a masterful architect or that you can build a stunningly beautiful home.

To get to the next level of mastery and understanding, that means you’ll need the Certified Professional.  If you take a look at the specific components that are tested you’ll quickly realize that advanced technical skill is weighted less than storytelling or analysis.  The purpose of the Desktop Certified Professional is to demonstrate that you have a deep understanding of data visualization, using data visualization to tell a story, and how level two (or three or four) analytics or analysis are necessary to start answering deeper and more important (read as: higher impact) questions.

For me to work on preparation here – the exam prep guide was only the beginning.  It assists in the structural components of 1) knowing how many questions there will be 2) estimating time available to spend on each question 3) examples of analytical/presentation depth required to demonstrate proficiency 4) variety of question types.

Probably the most intriguing questions for me are those where you have to assess a particular visualization, give and justify a critique (and specifically how it relates to a described objective) and then provide an alternative solution (also justifying verbally the importance).  This skill is much different than knowing how to hammer a nail into a post.  It is defending why you chose to put a porch on the northeast corner of a home.  It’s a lot about feel.

I had such an awesome time taking the exam.  There are a lot of real world constraints that required me to distill down the most important components of each question.  It’s interesting because for most items there isn’t a single right answer.  There are definitely lots of wrong answers, but right is a spectrum that is somewhat dependent on your ability to communicate out the completeness of your point of view.

I’ve had the title of Tableau Desktop Certified Professional for just over a year now – so I can tell you with a decent amount of retrospective thought what it has done for me.  Just as I am able to describe the test and purpose it served in this blog post – I can do the same thing in all of my interactions.  It keeps me humble to knowing that the PURPOSE behind a visual display is more important than fancy widgets or cool tricks.  That to a large extent my role is to work through the semantics of a situation and get to the root of it.  The root of the question or questions, the heart of concern, the why behind the visualization.  And also the artistry (yes I use this word) behind what it takes to get there.  We have all felt the difference between a perfectly acceptable visualization and the right visualization.  The end user experiences something different.  I firmly believe that deeper understanding can be achieved by spending that extra thoughtfulness and approach to iteration.

So let’s now fast forward to the other certification path – the more recent one: Tableau Server.  What’s interesting is that because my strengths have been built out on the visualization end, I haven’t planted myself in an opportunity to understand the deeper technical components of Tableau Server.  I have always understood and had great depth of knowledge in Site Administration.  That is to say acknowledging and abiding by best practices for sharing, permissions, and managing content.  But – the part that I had not spent time on is creating a sustainable platform to have the vision continuously executed.

So to overcome that minor blind spot – I went on a mission to learn more, to shine light on the unknown.  You’ve seen that play out here on my blog – going on a self directed adventure to deploy a Server on Azure.  Nobody told me to do that – I was internally compelled.  (I should also mention I was honored to have a friend go on the journey with me!)

I’m probably rehashing at this point – but anytime you grow knowledge in a particular area (more specifically technical) it gives you such breadth and depth of vocabulary to be able to connect to other individuals.  You find that communication barriers that were preventing the success of a project are diminished because you now speak the same language.  As I write this I can hear Seth Godin saying that the more knowledge someone has in a particular subject area the more ABSTRACT their language is around it.  Which means that it is extremely difficult to communicate with that SME unless significant effort is taken on the part of both parties to bridge the gap.

So that’s what Tableau Server qualification has done for me.  It’s the first step on a journey to get to the point where I imagine the next level to Server Certified Professional is the act of execution.  It’s less knowledge and verbiage and more tactical.  Also likely there’s more ambiguity – not a right answer, rather a spectrum of right where you communicate your why.

As I wind down this post – I must shout to you “go get certified.”  Ignore the naysayers.  It’s easy to not do something, but you know what is hard?  Doing something.  Being tested.  And why is that?  Because you can fail.  Get over failure – push through that mindset.  The alternative is much more pleasant and unlocks all the potential the universe has to offer.



Star Trek The Next Generation: Every Episode (#IronViz 3)

It’s that time again – Iron Viz feeder contest!  The third and final round for a chance to battle at conference in a chef coat is upon us.  This round the focus was on anything ‘Silver Screen.’

With a limitless topic I was certain that I would find myself in a creative rut that would likely result in submitting something at the end of the submission time period (August 13th).  So I am as shocked as anyone else that I have a fully formed submission way before deadline.

So what’s the topic and what got me unstuck?  Star Trek of course!  The backstory here is amazing – I went to a belated wedding shower for a few friends and they mentioned to me that they were going to the annual Star Trek convention.  And more specifically there was a special celebration occurring – the 30th anniversary of Star Trek: The Next Generation.  Not even up for debate – it just IS the best incarnation of the Star Trek universe.

So I decided to take a moment to do some research on finding TNG data.  It didn’t take me long to unearth this fantastic data set on GitHub that includes each episode’s script parsed out by character.

Really inspired by the thought of seeing each word of each episode visualized – I set forth on my mission.  As I got started there was one component that was mission critical: the bold colors present throughout the world of Star Trek.  The bold and moody colors of Star Trek are fantastic – especially paired with a black background.  And working with individual scripts meant that I could use color to accentuate different characters – much like their uniforms do in the episodes.

The next component that I wanted to invoke on this (again – design focused here) was the electronics and computer interfaces.  I particularly like the rounded edges and strong geometric shapes that are on the computer screens across all iterations of Star Trek.  So that describes most of the design – the choice of colors and how some of the visualizations were setup.

Now on to the next important component here: analysis.  When you see this visualization you may find yourself realizing that I don’t draw any conclusions.  For this collection of visualizations I am playing the role of curator.  I am developing a visual world for you to interact with, to go deep and wide in your understanding.  I am not attempting to summarize data for you or force conclusions upon you.  I am inviting you to come into the world of Star Trek, unearth who speaks during each episode, find out what that character is saying.  I want there to be an unending number of takeaways and perceptions generated from this.

And the last part you need to understand is the story telling.  This entire visualization has an untold number of stories in it by virtue of it being a visualization of the entire series.  If you want a meta-story to tell it’s simply this: Star Trek The Next Generation is such a deep and rich world that you should go get lost.  And while you’re on the path of getting lost do me a favor: retain some leadership tidbits from Picard and sprinkle in some logical takeaways from Data.
